MAN B&W 19.10
Page 2 of 10
MAN Diesel
MAN B&W L35MC6 198 77 88-1.0
Pos. Description
Mass Dimensions (mm)
(kg) A B C D E
1 Guide ring for piston 13 55 460
2 Lifting tool for piston 6 313 85 305 20 40
3 Support iron for piston 24 625 410 350
Fig. 19.10.01: Dimensions and masses of tools
122 66 40-0.1.0
B
A
122 66 25-7.1.0
C
D
B
E
A
122 66 29-4.1.0
C
A
B
2
1 3
