 Physical outputs descriptions
Bit Description
0 to 15 Reserved
16
Forced output of DO#1(I/O pin 35, 36)(0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.16) is set to 1
17
Forced output of DO#1(I/O pin 37, 38) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.17) is set to 1
18
Forced output of DO#1(I/O pin 39, 40) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.18) is set to 1
19
Forced output of DO#1(I/O pin 41, 42) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.19) is set to 1
20
Forced output of DO#1(I/O pin 43, 44) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.20) is set to 1
21
Forced output of DO#1(I/O pin 45, 46) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.21) is set to 1
22
Forced output of DO#1(I/O pin 47, 48) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.22) is set to 1
23
Forced output of DO#1(I/O pin 49, 50) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.23) is set to 1
24 DO #1output status (0:OFF, 1:ON)
25 DO #2output status (0:OFF, 1:ON)
26 DO #3 output status (0:OFF, 1:ON)
27 DO #4output status (0:OFF, 1:ON)
28 DO #5output status (0:OFF, 1:ON)
29 DO #6output status (0:OFF, 1:ON)
30 DO #7output status (0:OFF, 1:ON)
31 DO #8output status (0:OFF, 1:ON)
Table 62. Physical Output Descriptions
 Bit mask descriptions
Bit Descriptions
0 to 15 Reserved
16 DO#1(I/O pin 35, 36)output status setting (0:Disable, 1:Enable)
17 DO#2(I/O pin 37, 38)output status setting (0:Disable, 1:Enable)
18 DO #3(I/O pin 39, 40)output status setting (0:Disable, 1:Enable)
19 DO #4(I/O pin 41, 42)output status setting (0:Disable, 1:Enable)
20 DO#1(I/O pin 43, 44)output status setting (0:Disable, 1:Enable)
21 DO#2(I/O pin 45, 46)output status setting (0:Disable, 1:Enable)
22 DO #3(I/O pin 47, 48)output status setting (0:Disable, 1:Enable)
23 DO #4(I/O pin 49, 50)output status setting (0:Disable, 1:Enable)
24 to 31 Reserved
Table 63. Bit Mask Descriptions
