Parker Hannifin
P Series User Guide 41
3.6.1 Internal Resistor Setting
This drive has a built-in regeneration brake corresponding to the drive power.
Specifications of internal regeneration brake for each drive power are as follows.
Drive Power
Internal Resistance
Power
Table 16. Internal Resistor Setting
To use the regeneration broke built in the drive, you should set the brake in the
following order.
A. Regeneration brake wiring
- Check for B, BI terminal short (default short at the time of release from the
factory, 1kW or less)
To Next Page
