P Series User Guide 278
2 HOME(origin sensor input)
3 to 15 Reserved
16 DI #1(I/O pin 12), 0:Open, 1:Close
17 DI #2(I/O pin 13), 0:Open, 1:Close
18 DI #3(I/O pin 14), 0:Open, 1:Close
19 DI #4(I/O pin 15), 0:Open, 1:Close
20
DI #5(I/O pin 16), 0:Open, 1:Close
21 DI #6(I/O pin 17), 0:Open, 1:Close
22
DI #7(I/O pin 18), 0:Open, 1:Close
23 DI #8(I/O pin 19), 0:Open, 1:Close
16 DI #9(I/O pin 22), 0:Open, 1:Close
17 DI #10(I/O pin 23), 0:Open, 1:Close
18 DI #11(I/O pin 24), 0:Open, 1:Close
19 DI #12(I/O pin 25), 0:Open, 1:Close
20 DI #13(I/O pin 26), 0:Open, 1:Close
21 DI #14(I/O pin 27), 0:Open, 1:Close
22 DI #15(I/O pin 28), 0:Open, 1:Close
23
DI #16(I/O pin 29), 0:Open, 1:Close
24~30 Reserved
31
Reserved
Table 110. Digital Input Status
0x60FE
Digital Outputs
SubIndex 0
Number of entries
Variable
Format
Setting Range
Default
Value
Unit
Accessib
ility
PDO
Allocation
Change
Property
Store
USINT
-
2
-
RO
No
-
No
SubIndex 1
Physical outputs
Variable
Format
Setting Range
Default
Value
Unit
Accessib
ility
PDO
Allocation
Change
Property
Store
UDINT
0 to 0xFFFFFFFF
0
-
RW
Yes
At all times
No
SubIndex 2
Bit mask
Variable
Format
Setting Range
Default
Value
Unit
Accessib
ility
PDO
Allocation
Change
Property
Store
UDINT
0 to 0xFFFFFFFF
0
-
RW
Yes
At all times
Yes
Show digital output status.
 Physical outputs descriptions
bit Descriptions
0 to 15
Reserved
16
Forced output of DO#1(I/O pin 35, 36) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.16) is set to
1
17
Forced output of DO#1(I/O pin 37, 38) (0:OFF, 1:ON)
Provided that the relevant bit mask (0x60FE:02.17) is set to
1
