Parker P Series User Manual

Parker Hannifin
P Series User Guide 197
0°
90°
180°
270°
60°
340°
8.3 Functions of Index Input Signal
 Pause
When the pause signal (rising edge) is input during index operation, the current index is
paused. The remaining distance is rotated when the pause signal (rising edge).is input
again.
 STOP
When the stop signal (Rising Edge) is input, the motor stops at the set deceleration
(0x6085), ending the index operation sequence.
When the start signal is input again, the operation resumes from the index set as the
start index (0x3008).
