P Series User Guide 73
C. Read Holding Register (0x03)
Reads the values of single register (16bit data) and continuous register block (16bit data
unit).
 Request
Function code
1Byte
0x03
Starting Address
2Byte
0x0000 to 0xFFFF
Quantity of Registers
2 Bytes
1 to 125 (0x7D)
 Request OK
Function code
1Byte
0x03
Starting Address
1Byte
2 x N*
Quantity of Registers
N* x 2 Bytes
*N = Quantity of Registers
 Response not OK
Error code
1Byte
0x83
Exception code
1Byte
0x01 ~ 0x06
Table 26. Read Holding Register
Example1) reading a single parameter (current speed (Address: 0x2600))
 Request
Node
ID
Functio
n
Starting
Address
Hi
Starting
Address
Lo
Quantity of
Register Hi.
Quantity of
Register Lo
CRC
Hi
CRC
Lo
0x01 0x03 0x26 0x00 0x00 0x01 0x8F 0x42
 Request OK
Node
ID
Function Byte Count
Register
Value Hi
Register
Value Lo
CRC Hi CRC Lo
0x01 0x03 0x02 0x00 0x00 0xB8 0x44
- The current speed value is 0(or 0x0000).
 Response not OK
Node ID Error Code
Exception
Code
CRC Hi CRC Lo
0x01 0x83 0x01 ~ 0x06 - -
Table 27. Example of Reading Single Parameter
Example 2) Reading multiple parameters (motor ID(Address: 0x2000), Encoder
Type(Address: 0x2001), number of encoder pulses per rotation (Address:
0x2002~0x2003))
 Request
Node
ID
Function
Starting
Address
Hi
Starting
Address
Lo
Quantity of
Register Hi.
Quantity of
Register Lo
CRC Hi
CRC Lo
0x01 0x03 0x20 0x00 0x00 0x04 0x4F 0XC9
