11.1 Troubleshooting Guidelines
Abnormality Diagnosis and Actions
Abnormality during operation sets off alarm or warning. In such cases, please check the
corresponding code and take appropriate actions. When the abnormality is not corrected after
such actions, please contact us at our service department.
11.2 Servo Alarm and Check List
Upon detecting abnormality, the drive sets off the servo alarm, and transitions to servo off status
ad stops. In such case, the stop method follows the set value of the emergency stop setting
(0x2013).
Alarm Code Causes Details What to check
IPM fault
Over current
Current limit
exceeded
Motor cable
error
Wiring is incorrect and check
short
Replace motor cable
Encoder
cable error
Wiring is incorrect and check
short
Replace encoder cable
Parameter
cable error
Motor ID [0x2000], encoder
type[0x2001], encoder
form[0x2002] setting value
should be same with applied to
motor label.
Modify motor label and
parameter concordantly
Check motor
phase
resistor
Check if U/V/W phase current
Offset(0x2015~0x2017) is 5%
or above of the rated current,
Replace drive
Replace motor
Machine part
has problem
Determine whether there is a
conflict or binding in the
equipment.
Check machine part
Drive error
If alarm continue after servo on
again, Replace drive. Because
drive may have problem.
Error by
noize
Check method to improve
noise of wiring, install.
Please check condition of
wiring for FG. Match wire size
of FG with wire size of drive
main circuit.
IPM temperature
surroundings
temperature
Check surrounding
temperature is over 50 [℃]
Lower surrounding
temperature
Continuous
Overload
alarm
Accumulated operate overload
percentage [0x2603] Checking
the load percentage is under
100%
Change drive and motor
capacity,
Please tune gain.
Adjust regeneration resistor
To Next Page
