P Series User Guide 45
3.7 Drive Status Indicators
7-Segment for servo status display consist of the following 5 digits, from Digit 1 to Digit 5,
starting from the right.
Digit 3~1 of 7 –Segment, unless the servo alarm is set off, displays the following drive
statuses. Display of servo warning is given priority over other statuses.
Digit 3~Digit 1 Display
Status Description
Servo off
Positive limit sensor input
Negative limit sensor input
Servo on
Servo warning: W10 (code:10)
Digit4 displays the current operation status and the servo’s READY status.
