Parker Hannifin
P Series User Guide 82
9238 0x2416
Individual Parameter
Store
0x240E UINT 0 0 1 - RW
Table 39. Miscellaneous Parameters
4.3.6 Advanced Control Parameters
parameter name
paramet
er No.
Variable
Format
Default
Value
Min Max Unit
Accessibil
ity
decimal
9472 0x2500
Adaptive Filter
Function Select
0x2500 UINT 0 0 5 - RW
9473 0x2501
0x2501 UINT 5000 50 5000 Hz RW
9474 0x2502 Notch Filter 1 Width 0x2502 UINT 1 1 100 Hz RW
9475 0x2503 Notch Filter 1 Depth 0x2503 UINT 1 1 5 - RW
9476 0x2504
0x2504 UINT 5000 50 5000 Hz RW
9477 0x2505 Notch Filter 2 Width 0x2505 UINT 1 1 100 Hz RW
9478 0x2506 Notch Filter 2 Depth 0x2506 UINT 1 1 5 - RW
9479 0x2507
0x2507 UINT 5000 50 5000 Hz RW
9480 0x2508 Notch Filter 3 Width 0x2508 UINT 1 1 100 Hz RW
9481 0x2509 Notch Filter 3 Depth 0x2509 UINT 1 1 5 - RW
9482 0x250A
0x250A UINT 5000 50 5000 Hz RW
9483 0x250B Notch Filter 4 Width 0x250B UINT 1 1 100 Hz RW
9484 0x250C Notch Filter 4 Depth 0x250C UINT 1 1 5 - RW
9485 0x250D
0x250D UINT 0 0 1 - RW
9486 0x250E
System Rigidity for
Gain Tuning
0x250E UINT 5 1 20 - RW
9487 0x250F
On-line Gain Tuning
Adaptation Speed
0x250F UINT 1 1 5 - RW
9488 0x2510
Off-line Gain Tuning
Direction
0x2510 UINT 0 0 1 - RW
9489 0x2511
Off-line Gain Tuning
Distance
0x2511 UINT 5 1 10 - RW
9490 0x2512
Disturbance
Observer Gain
0x2512 UINT 0 0 100 % RW
9491 0x2513
Observer Filter Time
0x2513 UINT 10 0 1000 0.1ms RW
9492 0x2514
0x2514 UINT 100 1 150 % RW
9493 0x2515
Suppression Filter
0x2515 UINT 0 0 5 - RW
9494 0x2516
Suppression Filter 1
0x2516 UINT 0 0 2000 0.1Hz RW
9495 0x2517
Suppression Filter 1
0x2517 UINT 0 0 5 - RW
9496 0x2518
Suppression Filter 2
0x2518 UINT 0 0 2000 0.1Hz RW
9497 0x2519
Suppression Filter 2
0x2519 UINT 0 0 5 - RW
Table 40. Advanced Control Parameters
4.3.7 Monitoring Parameters
parameter name
parameter
No.
Variable
Format
Default
Value
Min Max Unit
Accessibilit
y
decimal
To Next Page
