6.5
PVT System
6
Drive Clutch Springs
NOTE: Springs listed as color - #### will have the last
four digits of the part number painted on the spring
coil. Tag each spring with the part number and spring
force when not in use.
PART NUMBER COLOR
WIRE
DIAMETER
(inch
es)
FREE LENGTH +/-
.12
5”
FORCE LBS.
@ 2
.50” - 1.19”
(+/- 12 LBS.)
LOAD
RATE (lbs./
inch)
7041080 Blue .207 3.55 120 - 300 137
7041945 Almond .218 3.65 140 - 330 145
7041645 Almond/Gold .207 4.00 150 - 290 107
7041818 Black/White .218 3.52 140 - 320 137
7041816 Almond/Black .200 3.75 165 - 310 111
7041922 Almond/Blue .218 3.75 150 - 310 122
7041988 Almond/Red .207 4.27 165 - 310 110
7042083 Black/Green .218 3.38 120 - 340 168
7043681 Black - 3681 .225 3.327 120 - 310 145
7043829 Black - 3829 .218 3.48 140 - 330 145
7043076 Black - 3076 .225 2.67 40 - 340 229
7043120 Black - 3120 .225 2.78 60 - 340 213
7043121 Black - 3121 .255 3.05 100 - 340 183
7042287 Black - 2287 .207 3.40 110 - 290 137
