10.23
Battery and Electrical Systems
10
ELECTRIC START
System Schematic
BATTERY CHARGE
CH / ENG GROUND
10A PROTECTED
DCV
RED
RD/DK
BRN -- DIRECT
DC--CFI ECU CNA CONNECTOR
AC REGULATOR
BATTERY CHARGE
YELLOW
AC STATOR
VOLTAGE
STARTER SOLENOID
M
STARTER
MOTOR
1
BATTERY
-
+
10A BREAKER
RED
3
KEY SWITCH
(CIRCUIT CLOSED
WHEN KEY TURNED
TO START)
DG/WH
WHITE
RED/BLK
WH/RD
RED
GROUND
CHASSIS/ELECTRIC START HARNESS
CONNECTOR
RED
RD/DK
