10.6
Battery and Electrical Systems
Performance Information Area
The performance information area (middle) of the display
screen is dedicated to displaying:
• Engine RPM or vehicle speed (whichever is not
displaye
d at the top of the screen)
• Maximum ground speed
• Maximum engine RPM
• Engine temperature (2011-current models only)
Press and release the MODE button on the instrument
cluster
or LH control to toggle between the different
displays.
Vehicle Information Area
The bottom of the instrument cluster screen is dedicated
to displaying the following information:
• Odometer
•Trip A
•Trip B
• Engine hours
Press and release the SEL button
on the instrument
cluster or SET button on the LH control to toggle between
the different displays.
To reset the Trip A and Trip B displays, press and hold the
SEL bu
tton on the instrument cluster or SET button on the
LH control for 3 seconds when the desired trip meter is
displayed on the screen. The counter will reset to 0.
NOTE: Engine hours and odometer cannot be reset.
Changing Units
The instrument cluster will display either standard or
metric units. Change between the two by following these
steps:
1. Press and release the SEL button on the instrument
cluster
or the SET button on the LH control until the
ODOMETER is displayed on the screen.
2. Once the ODOMETER is displayed, press and hold
e
ither the SEL button or SET button for 3 seconds until
the units change.
Diagnostic Display
The instrument cluster can display diagnostic trouble
codes (DTCs) when, and only when, the check engine
MIL is illuminated.
To display DTCs, follow these steps:
1. When an active DTC is realize
d, the check engine MIL
will illuminate.
NOTE: The instrument cluster will display historic
DT
Cs, but only during the same power cycle. All
codes stored in the instrument cluster are lost when
the instrument cluster is powered down.
2. Keep the engine running. Press and release the SEL
button o
n the instrument cluster or the SET switch on
the LH control until the diagnostics mode is activated.
Once activated, the check engine MIL will begin
flashing and “Err” will be displayed on the screen.
3. The diagnostics mode will dis
play the SPN and FMI
codes. A list of codes can be found in chapter four.
4. To check for multiple codes, press and hold the SEL
button o
n the instrument cluster for 2 seconds until a
new code is displayed. Repeat until no new codes are
displayed.
5. To exit the diagnostics mode, either turn off the engine
or pr
ess and release the SEL button on the instrument
cluster.
Playback Mode
The instrument cluster can be used as an engine RPM,
vehicle speed, and TPS data recorder. Once enabled, the
gauge can record up to three minutes of information.
To initiate RECORD:
1. Press and hold the MODE and SEL buttons on the
inst
rument cluster for 3 seconds.
2. The PLAY BACK icon will begin flashing when record
is activa
ted.
To PLAY BACK:
1. Once the snowmobile has stopped and the engine
RPM d
rops below clutch engagement speed, press
and hold the MODE and SEL buttons on the
instrument cluster to enter the play back mode.
2. To exit the play back mode, slightly tap the throttle
lever.
