130
2
Set the [Mix Color] button in the [Edge Matte] group
to the on state and set the following parameters.
a) Linked to the pattern number selected using the [Mix Pattern
Select] button.
To set a single color, set the [Flat Color] button to the
on state.
The [Flat Color] button parameters are shared with
t
he [Matte] button parameters in the [Edge Fill] group
in the Home > M/E-1 > Key1 > Edge > Edge Type
Select menu (11101.21).
3
Press the [Mix Pattern Select] button.
A pattern selection window appears.
Dedicated patterns 1 to 24 are the same as standard
wi
pe patterns 1 to 24.
4
Set the button for the target pattern to the on state.
5
Press [OK].
6
Press the [Color 1] button and set color 1 using the
following parameters.
The [Color 1] button parameters are shared with the
[
Matte] button parameters in the [Edge Fill] group in
the Home > M/E-1 > Key1 > Edge > Edge Type
Select menu (11101.21).
7
Press the [Color 2] button and set color 2 using the
following parameters.
To swap color 1 and color 2 in a color mix
Set the [Color Invert] button to the on state.
To set modifiers for a dedicated pattern for a
co
lor mix
You can set the following modifiers.
Position:
Set the [Position] button to the on state and set the
p
arameters.
For details about setting parameters, see “Setting the
wipe pattern position (Position)” (page 158).
Multiplication:
Set the [Multi] button to the on state and set the
p
arameters.
For details about setting parameters, see
“Replicating a wipe pattern (Multi)” (page 159).
Aspect:
Set the [Aspect] button to the on state and set the
p
arameters.
For details about setting parameters, see “Setting the
aspect ratio of a wipe pattern (Aspect)” (page 159).
Rotation (angle):
Set the [Angle] button in the [Rotation] group to the
on
state and set the parameters.
For details about setting parameters, see “Rotating a
wipe pattern (Rotation)” (page 158).
Rotation (speed):
Set the [Speed] button in the [Rotation] group to the
on
state and set the parameters.
For details about setting parameters, see “Rotating a
wipe pattern (Rotation)” (page 158).
Setting Key Edges (Key Control
Block)
Select the target key to set and press the page selection
button to display page 2/3 of the setting buttons.
In the key control block, you can set the edge type using
t
he following buttons.
• [BDR] button: Border
• [DROP BDR] button: Drop border
• [SHDW] button: Shadow
• [SOFT EDGE] button: Soft edge
For details about key control block operations, see
“Setting the Key Type (Key Control Block)” (page 119).
No. Parameter Adjustment
1 Size Pattern size
2 Soft Softness of the pattern
co
ntour
5 Pattern Pattern number
a)
Note
Note
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
Note
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
No. Parameter Adjustment
