• Home > Setup > Switcher > Config > PGM Config
menu (19103.13)
• Home > Setup > Switcher > Config > K-PVW Config
men
u (19103.14)
The settings are common to all switcher banks.
1 Open the Home > Setup > Switcher > Config > M/E
Config menu (19103.12).
2 Set the [Recall M/E Config] button to the on state.
Setting Extended Re-Entry
When extended re-entry is enabled, selection of re-entry
signals on the same switcher bank becomes possible.
In multi program 2 mode, selection of re-entry signals
bet
ween main and sub also becomes possible.
• The extended re-entry settings are common to all
swi
tcher banks.
• Stacked re-entry may cause problems in the image.
• The selection order of re-entry signals affects the
nu
mber of lines by which the output signal is lowered.
1 Open the Home > Setup > Switcher > Config > M/E
Config menu (19103.12).
2 Set the [Extended M/E Re-Entry] button to the on
state.
3 Check the message, then press [OK].
Setting a DME Channel
Setting a DME channel to use in a
switcher bank
You can set a DME channel to use on switcher bank for a
processed key or DME wipe.
1 Open the Home > Setup > Switcher > Config > DME
Config menu (19103.16).
2 Select the target switcher bank to set.
3 Press the [Edit] button for [DME Channel].
The [Select DME Channel] window appears.
4 Place a check mark in the DME channels to enable.
5 Press [OK].
Setting a User Region
You can assign the following regions to User 1 to User 8.
• Color Bkgd 1, Color Bkgd 2
• Aux 1 to Aux 48
• Frame Memory 1 to Frame Memory 16
• Clip Player 1 to Clip Player 4
If you change the user region settings, the previously
saved
snapshot data and effect timeline data can no longer
be used.
1 Open the Home > Setup > Switcher > Config > User
Region Config menu (19103.17).
2 Select the target region to set.
To select and set multiple regions, place a check mark
besi
de the target regions to set.
To select and set all regions, place a check mark in the
Sel
ect All checkbox.
3 Press the [User Region] button and select a user
region (User 1 to User 8) from the pull-down list.
When you do not want to assign a user region
Select [No Assign] from the pull-down list.
To return to the previous setting
Press the [Clear] button.
4 Press the [Apply] button.
5 Check the message, then press [OK].
Notes
Note
