Sony MKS-XIC01 User Manual

202
You can also enter a difference value from the currently
set value using the [TRIM] button.
For details, see “Entering a difference from a current
value” (page 79).
To change parameters to the closest detent
po
sition
Press the [CTR] button once.
For details about detents, see “Detents” (page 196).
To return the parameters to the default values
Press the [CTR] button twice. Or press and hold the
[
SHIFT] button and press the [CTR] button.
For details about default values, see “Three-dimensional
parameter setting values” (page 195).
To return parameters to the initial settings
The parameters return to the initial status saved data
se
tting values.
The operation must be performed separately for global
spac
e and local space.
For details about initial status, see “Setting Startup”
(page 359).
To return three-dimensional parameters to the initial
setti
ngs:
Press the [CLR WORK BUFR] button once.
To return all DME parameters to the initial settings:
Press the [CLR WORK BUFR] button twice. Or press
an
d hold the [SHIFT] button and press the [CLR
WORK BUFR] button.
Three-Dimensional Transform
Operations (Menu)
This section describes the menu for DME channel 1 as an
example.
Adjusting three-dimensional parameters
1 Open the Home > DME > Channel1 > 3D Transform
> Adjust menu (15101.11).
2 In the [Local/Global] group, select local space or
global space.
Local: L
ocal space
Global: Gl
obal space
Both local space and global space can be selected.
3 In the [Source/Target] group, select source space or
target space.
Source: S
ource space
Target: T
arget space
Either source space or target space can be selected.
4 Set the target three-dimensional transform operation
X-axis, Y-axis, and Z-axis parameters.
When local space is selected
Press the [X] button, [Y] button, or [Z] button for
[L
ocal], and enter a setting value in the numeric
keypad window.
When global space is selected
Press the [X] button, [Y] button, or [Z] button for
[Gl
obal], and enter a setting value in the numeric
keypad window.
To adjust parameters using the analog controls
secti
on
Press the button for the target three-dimensional
tr
ansform operation to set, and set the [X] parameter,
[Y] parameter, and [Z] parameter in the analog
controls section.
When both local space and global space are selected,
t
he parameter buttons for local space are displayed on
the 1st page and the parameter buttons for global
space are displayed on the 2nd page. Set the
parameters for local space on the 1st page and the
parameters for global space on the 2nd page.
Configurable three-dimensional parameters
The parameters that can be set vary depending on the
th
ree-dimensional transform operation buttons.
Location Size: Scal
e image (shrink/magnify)
Only the Z-axis in source space can be configured.
All axes in target space can be configured.
Location XYZ: Move imag
e
All axes can be configured.
Rotation: Ro
tate image (rotation mode)
All axes can be configured.
Spin: Ro
tate image (spin mode)
All axes can be configured.
Aspect: Chang
e image aspect ratio
Only the source space of the local space can be
c
onfigured.
Skew: Chan
ge image skew
Only the X-axis and Y-axis in the source space of the
l
ocal space can be configured.
Perspective: C
hange viewpoint position
Only target space can be configured.
Axis Location: M
ove rotation axis
Only source space can be configured.
To change parameters to the closest detent
po
sition
Press the [Detents] button.
Note
