Chapter
424
25
External Device Setup
Copying External Device Settings Information
When using two control panels in a switcher system,
ext
ernal devices are controlled by control panel 1.
Consequently, the external device settings information
for control panel 1 must be copied to control panel 2.
Copy the external device setup data using the Home >
F
ile menu, for example.
For details about Home > File menu operations, see
“Chapter 19 File Management” (page 329).
Setting Parallel Input
Ports
The use of parallel input ports is assigned in the following
priority sequence.
1. External box settings in the Home > Setup >
R
outer/Tally > NS-Bus > Matrix menu (19106.11).
Assigned to external boxes according to the parallel
i
nput port priority.
2. Tally settings in the Home > Setup > Router/Tally
>
Tally > Tally Enable menu (19106.23).
Tally input is assigned to the selected parallel input
por
t.
3. GPI input port settings in the Home > Setup >
Ex
ternal Device > Input Config menu (19105.11).
GPI input settings are configured for parallel input ports
not
used for external boxes or tally input.
GPI input is also supported via a network. The GPI input
p
ort settings are the same as for parallel input ports.
For details, see “GPI input via a network” (page 425).
Assigning a GPI Input
1
Open the Home > Setup > External Device > Input
Config menu (19105.11).
A list of parallel input ports is shown on the left and
a
list of GPI inputs is shown on the right.
2
In the list on the left, select the target parallel input
port to set.
The number for a parallel input port is displayed in
“lo
gical box ID (1 to 3) -board (1 to 3) -number (1 to
6)” format (for example, “1-3-6”).
To Next Page
