Sony MKS-XIC01 User Manual

161
2 Press and hold the [WIPE] button and press the button
for the target register to save.
The register button is lit orange and the wipe settings
are saved i
n the snapshot.
If you press a register button in which a wipe
sn
apshot is already saved, the register data will be
overwritten.
Recalling a wipe snapshot
1 Press the [WIPE] button.
The memory recall section switches to wipe snapshot
o
peration mode.
2 Press the button for the target register to recall.
The register button is lit orange and the wipe snapshot
is re
called.
To undo a register recall
To undo a recall immediately after recalling a register,
press the
[UNDO] button.
Deleting a wipe snapshot
1 Press the [WIPE] button.
The memory recall section switches to wipe snapshot
o
peration mode.
2 Press and hold the [DEL] button and press the button
for the target register to delete.
The wipe snapshot is deleted and the register button
ch
anges to register number display.
Wipe Snapshot Operations (Menu)
The same memory recall buttons as in the memory recall
section of the Flexi Pad control block are displayed in the
Bus/Transition > Wipe > Wipe Snapshot menu on the
switcher bank. The settings and display of the memory
recall buttons in the Flexi Pad control block and in the
menu are linked.
This section describes the M/E-1 menu as an example.
Selecting a wipe pattern
1 Open the Home > M/E-1 > Bus/Transition > Wipe >
Wipe Snapshot menu (11109.37).
2 Press the [Current Pattern] button and enter a pattern
number in the numeric keypad window.
The icon for the selected wipe pattern is displayed on
t
he right side of the [Current Pattern] button.
Saving a wipe snapshot
Set a wipe and save a wipe snapshot register using the
following procedure.
1 Open the Home > M/E-1 > Bus/Transition > Wipe >
Wipe Snapshot menu (11109.37).
2 Press the [Store] button in the [Mode] group.
3 Press the button for the target register to save.
The register button is lit orange and the wipe settings
are sav
ed in the snapshot.
If you press a register button in which a wipe
snap
shot is already saved, the register data will be
overwritten.
Recalling a wipe snapshot
1 Open the Home > M/E-1 > Bus/Transition > Wipe >
Wipe Snapshot menu (11109.37).
2 Press the [Recall] button in the [Mode] group.
3 Press the button for the target register to recall.
The register button is lit orange and the wipe snapshot
i
s recalled.
Deleting a wipe snapshot
1 Open the Home > M/E-1 > Bus/Transition > Wipe >
Wipe Snapshot menu (11109.37).
2 Press the [Delete] button in the [Mode] group.
3 Press the button for the target register to delete.
The wipe snapshot is deleted and the register button
chan
ges to register number display.
Note
Note
