Setting a Parallel Tally
You can set the output port for a parallel tally.
1 Open the Home > Setup > Router/Tally > Tally >
Parallel Tally menu (19106.26).
2 Select the target parallel output port to set.
To select and set multiple ports, place a check mark
be
side the target ports to set.
To select and set all ports, place a check mark in the
S
elect All checkbox.
You can also press the [Select Number(s)] button and
en
ter a port number in the numeric keypad window.
Ports on boards 2 and 3 can be used when an
M
KS-X1700 Legacy Interface Board (option) is
installed.
3 Press the [Tally Assign] button and select a type of
tally from the pull-down list.
Src Tally:
Set source tally. Return a tally to the
sources that are output to the destinations.
Dest Tally: S
et destination tally. Return a tally to the
destinations outputting sources that return a tally
using source tally.
To set a source tally
1 Select the target parallel output port to set.
2 Press the [Source] button and enter a source address
in the numeric keypad window.
3 Press the [Edit] button for [Tally Type].
The [Select Tally Type] window appears.
4 Set the button for the target tally to the on state.
R1 to R8: Ta
lly type 1 to 8 for red tally
G1 to G8: T
ally type 1 to 8 for green tally
Y1 to Y8: Ta
lly type 1 to 8 for yellow tally
5 Press [OK].
To set a destination tally
1 Select the target parallel output port to set.
2 Press the [Destination] button and enter a destination
address in the numeric keypad window.
3 Press the [Level] button and enter a level (1 to 8) in
the numeric keypad window.
4 Press the [Edit] button for [Tally Type].
The [Select Tally Type] window appears.
5 Set the button for the target tally to the on state.
R1 to R8: Tally
type 1 to 8 for red tally
G1 to G8: T
ally type 1 to 8 for green tally
Y1 to Y8: Ta
lly type 1 to 8 for yellow tally
6 Press [OK].
To delete a parallel tally setting
Select the target parallel tally to delete and press the
[C
lear] button.
Note
