Sony MKS-XIC01 User Manual

138
• A resizer and dual resizer effects cannot be used on
additional keys.
Two-Dimensional Transforms on
Keys
Reducing, enlarging, moving, and rotating
keys (menu)
1 Open the Home > M/E-1 > Key1 > Resizer/Proc Key
> Resizer Adjust/DME Select menu (11101.41).
2 Set the [Resizer] button to the on state and set the
following parameters.
a) When the [X] button is selected in the [Rotation] group
b) When the [Y] button is selected in the [Rotation] group
For details about selecting the rotation direction, see
“Rotating a key (menu)” (page 139).
Reducing, enlarging, moving, and rotating
keys (key control block)
For details about key control block operations, see
“Setting the Key Type (Key Control Block)” (page 119).
1 Press the [M/E-1] button, turning it on.
2 Press the [KEY1] button, turning it on.
3 Press the [RSZR] button, turning it on.
4 Set the following parameters.
a) When the [ROT X] button is selected
b) When the [ROT Y] button is selected
For details about selecting the rotation direction, see
“Rotating a key (key control block)” (page 140).
Reducing, enlarging, moving, and rotating
keys (device control block)
Switch the device control block to resizer operation mode
to operate a two-dimensional transform.
1 Press the [M/E 1] button.
The [M/E 1] button is lit green, and the device control
bl
ock switches to M/E-1 resizer operation mode.
You can select multiple switcher banks. The first
sel
ected button becomes the reference channel, and is
lit green. Subsequent selected buttons are lit amber.
2 Press the [K1RSZ] button.
The [K1RSZ] button is lit green, and key 1 becomes
t
he target of resizer operations.
You can select multiple keys. The first selected
but
ton becomes the reference channel, and is lit
green. Subsequent selected buttons are lit amber.
3 Press the [RSZR ON] button.
The [RSZR ON] button turns on and the resizer is
enab
led.
4 Transform the key.
To change the aspect ratio of a key
Press the [ASP PERS] button, turning it on, and
a
djust the setting values using the trackball/Z-ring.
No. Parameter Adjustment
1-1 Location X Movement in horizontal
di
rection
1-2 Location Y Movement in vertical direction
1-3 Size Size of key
1-4 Rotation X Rotation around X-axis
a)
Rotation Y Rotation around Y-axis
b)
1-5 Perspective Viewpoint position
(perspective)
2-1 Aspect X Aspect ratio in horizontal
di
rection
2-2 Aspect Y Aspect ratio in vertical
di
rection
2-3 Aspect Ratio Simultaneous adjustment of
as
pect ratio in horizontal
direction and vertical direction
No. Parameter Adjustment
1-1 LOC X Movement in horizontal
di
rection
1-2 LOC Y Movement in vertical direction
1-3 SIZE Size of key
1-4 ROT X Rotation around X-axis
a)
ROT Y Rotation around Y-axis
b)
1-5 PERS Viewpoint position
(perspective)
2-1 ASPECT X Aspect ratio in horizontal
di
rection
2-2 ASPECT Y Aspect ratio in vertical
di
rection
2-3 ASPECT R Simultaneous adjustment of
as
pect ratio in horizontal
direction and vertical
direction
