YH4
GRAND
VITARA
FRONT DRIVE SHAFT/SHAFT BEARING, OIL SEAL 4A2-11
09913-75520
Bearing installer
09924-74510
Installer attachment
09930-30102
Sliding shaft
09941-64510
Bearing remover
09951-16090
Oil seal installer
TIGHTENING TORQUE SPECIFICATIONS
p
Tightening torque
N
.
m kg-m lb-ft
Drive shaft flange nut (Dif. side) 50 5.0 36.5
Oil level plug 23 2.3 17.0
Drain plug 23 2.3 17.0
Axle shaft drive flange bolt 48 4.8 35.0
NOTE:
Refer to standard tightening torque specifications, if no description or specification is provided.
REQUIRED SERVICE MATERIALS
MATERIAL
RECOMMENDED
SUZUKI PRODUCT
USE
Joint grease
(Molybdenum grease)
SUZUKI SUPER GREASE H
(99000-25120)
Drive axle joint
Lithium grease
SUZUKI SUPER GREASE A
(99000-25010)
Drive shaft oil seal
Wheel spindle part of differential side
drive shaft (RH)
Sealant
SEALING COMPOUND 366E
(99000-31090)
Axle shaft drive flange
SPECIAL TOOLS
