YH4

GRAND

VITARA

5-18 BRAKES

09950-78220

Flare nut wrench (10 mm)

09900-20205

Micrometer (0 – 25 mm)

09956-02310

Fluid pressure gauge

09956-02210

Brake circuit plug

09952-36310/09952-46510

Pressure gauge attachment

SPECIAL TOOLS
