YH4
GRAND
VITARA
8G
IMMOBILIZER CONTROL SYSTEM (IF EQUIPPED) 8G-1
GENERAL DESCRIPTION 8G- 2. . . . . . . . . . . . . .
Ignition Key 8G- 3. . . . . . . . . . . . . . . . . . . . . . . . . .
Coil Antenna 8G- 3. . . . . . . . . . . . . . . . . . . . . . . . .
Immobilizer Control Module 8G- 4. . . . . . . . . . . .
ECM/PCM 8G- 4. . . . . . . . . . . . . . . . . . . . . . . . . . .
On-Board Diagnostic System
(Self-Diagnosis Function) 8G- 4. . . . . . . . . . . . .
DIAGNOSIS 8G- 6. . . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions in Diagnosing Troubles 8G- 6. . . . .
Diagnostic Flow Table <Vehicle equipped
with monitor coupler> 8G- 9. . . . . . . . . . . . . . . .
Diagnostic Flow Table <Vehicle not
equipped with monitor coupler> 8G-10. . . . . . .
Diagnostic Trouble Code Check
(Immobilizer Control Module) 8G-11. . . . . . . .
Diagnostic Trouble Code Check
(ECM/PCM) 8G-11. . . . . . . . . . . . . . . . . . . . . .
Diagnostic Trouble Code Table 8G-13. . . . . . . . .
TABLE A DTC is not Output
from Diagnostic Output Terminal 8G-14. . . . . . .
TABLE B Immobilizer Indicator Lamp
Check (Immobilizer Indicator Lamp
does not Light at Ignition Switch ON) 8G-15. . .
TABLE C Immobilizer Indicator Lamp
Check (Immobilizer Indicator Lamp
Remains on after Engine Starts) 8G-16. . . . . . .
DTC11 Transponder Code Not Matched 8G-17. .
DTC31 Transponder Code Not
Registered 8G-17. . . . . . . . . . . . . . . . . . . . . . . . .
DTC12 Fault in Immobilizer
Control Module 8G-17. . . . . . . . . . . . . . . . . . . . . .
DTC13 No Transponder Code Transmitted
or Coil Antenna Opened/Shorted 8G-18. . . . . .
DTC21 ECM/Immobilizer Control Module
Code Not Matched (Immobilizer Control
Module Side) 8G-20. . . . . . . . . . . . . . . . . . . . . . .
DTC81 (P1623) ECM/Immobilizer
Control Module Code Not Matched
(ECM/PCM Side) 8G-20. . . . . . . . . . . . . . . . . . . .
DTC84 (P1620) ECM/Immobilizer Control
Module Code Not Registered 8G-20. . . . . . . . .
DTC22 Ignition Switch Circuit Open/Short 8G-21. .
DTC23 No ECM/Immobilizer Control
Module Code Transmitted from ECM/
PCM or DLC Circuit Opened/Shorted 8G-22. . . .
DTC83 (P1621) No ECM/Immobilizer
Control Module Code Transmitted from
Immobilizer Control Module or DLC
Circuit Opened/Shorted 8G-22. . . . . . . . . . . . . .
DTC82 (P1622) Fault in ECM/PCM 8G-23. . . . .
Inspection of ECM/PCM, Immobilizer
Control Module and Its Circuit 8G-24. . . . . . . . .
Voltage Check 8G-24. . . . . . . . . . . . . . . . . . . . .
Resistance Check 8G-25. . . . . . . . . . . . . . . . . .
ON-VEHICLE SERVICE 8G-26. . . . . . . . . . . . . . . .
Precautions in Handling Immobilizer
Control System 8G-26. . . . . . . . . . . . . . . . . . . . .
Immobilizer Control Module 8G-27. . . . . . . . . . . .
Coil Antenna 8G-27. . . . . . . . . . . . . . . . . . . . . . . . .
HOW TO REGISTER IGNITION KEY 8G-28. . . . .
PROCEDURE AFTER IMMOBILIZER
CONTROL MODULE REPLACEMENT 8G-29. .
PROCEDURE AFTER ECM/PCM
REPLACEMENT 8G-30. . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOLS 8G-30. . . . . . . . . . . . . . . . . . . . . .
SECTION 8G
IMMOBILIZER CONTROL SYSTEM
(IF EQUIPPED)
WARNING:
For vehicles equipped with Supplemental Restraint (Air Bag) System
Service on and around the air bag system components or wiring must be performed only by an autho-
rized SUZUKI dealer. Refer to “Air Bag System Components and Wiring Location View” under “Gener-
al Description” in air bag system section in order to confirm whether you are performing service on
or near the air bag system components or wiring. Please observe all WARNINGS and “Service Precau-
tions” under “On-Vehicle Service” in air bag system section before performing service on or around
the air bag system components or wiring. Failure to follow WARNINGS could result in unintentional
activation of the system or could render the system inoperative. Either of these two conditions may
result in severe injury.
Technical service work must be started at least 90 seconds after the ignition switch is turned to the
“LOCK” position and the negative cable is disconnected from the battery. Otherwise, the system may
be activated by reserve energy in the Sensing and Diagnostic Module (SDM).
CONTENTS
