YH4
GRAND
VITARA
BRAKES 5-17
TIGHTENING TORQUE SPECIFICATIONS
p
Tightening torque
N
.
m kg-m lb-ft
Brake pipe 2-way (or 4-way) joint bolt 23 2.3 17.0
Brake pipe flare nut 16 1.6 11.5
p
M8 8.0 0.8 6.0
p
M10 8.5 0.85 6.5
Wheel cylinder 7.5 0.75 5.5
LSPV 7.5 0.75 5.5
LSPV mounting bolt
LSPV stay bolt
23 2.3 17.0
LSPV spring nut
Wheel nut 100 10.0 72.5
Stop light switch lock nut 7.5 0.75 5.5
REQUIRED SERVICE MATERIAL
MATERIALS
RECOMMENDED
SUZUKI PRODUCT
USE
Brake fluid
Indicated on reservoir
cap or described in owner’s
manual of vehicle
To fill master cylinder reservoir.
To clean and apply to inner parts of master
cylinder caliper and wheel cylinder when
they are disassembled.
To Next Page
