10B-14 AIR BAG SYSTEM
DIAGNOSTIC TROUBLE CODE TABLE (Page 1 of 2)
EXAMPLE: WHEN DRIVER AIR BAG INITIATOR CIRCUIT RESISTANCE HIGH (CODE NO.21) IS SET
Turn ON
Turn OFF
0.3
0.3
1.0 3.0 3.0
Malfunction indicator lamp
(“AIR BAG” warning lamp)
Code No. 21 Code No. 21 Code No. 21
Time (sec.)
DIAGNOSTIC TROUBLE CODE
DIAGNOSIS
NO. MODE
DIAGNOSIS
12 Normal –––––
15 Resistance high
16
Passenger
air bag
Resistance low
18
air
bag
circuit
Short to ground
19 Short to power circuit
21 Resistance high
Diagnose trouble
according to “Diagnos-
tic Flow Table
”
corre-
22
Driver air bag
Resistance low
tic
Flow
Table
corre
-
sponding to each code
No.
24
g
circuit
Short to ground
25 Short to power circuit
31
Power
source
Too high
32
source
voltage
Too low
