YH4
GRAND
VITARA
ANTILOCK BRAKE SYSTEM (ABS) (OPTIONAL) 5E1-21
1. Ignition switch
2. G sensor
3. ABS hydraulic unit control
module assembly
4. ABS hydraulic unit/
control module
connector of harness
O/G
DTC 15 (DTC C1015) – G SENSOR CIRCUIT (FOR 4WD MODEL ONLY)
DESCRIPTION
While a vehicle is at stop or running, if the potential difference between the sensor signal terminal “A14” and the
sensor ground terminal “A4” is not within the specified voltage value, or if the signal voltage while at a stop does
not vary from that while running, this DTC is set.
Therefore, this DTC may be set when a vehicle is lifted up and its wheel(s) is turned. In such case, clear the DTC
and check again.
