YH4
GRAND
VITARA
5E1
ANTILOCK BRAKE SYSTEM (ABS) (OPTIONAL) 5E1-1
GENERAL DESCRIPTION 5E1- 2. . . . . . . . . . . . . .
Brake Hose/Pipe Routing 5E1- 3. . . . . . . . . . . . . .
System Schematic 5E1- 4. . . . . . . . . . . . . . . . . . . .
ABS Component Parts Location 5E1- 5. . . . . . . .
ABS Hydraulic Unit/Control Module
Assembly 5E1- 6. . . . . . . . . . . . . . . . . . . . . . . . . .
DIAGNOSIS 5E1- 7. . . . . . . . . . . . . . . . . . . . . . . . . . .
Precaution in Diagnosing Troubles 5E1- 7. . . . . .
ABS Diagnostic Flow Table 5E1- 8. . . . . . . . . . . .
EBD Warning Lamp (Brake Warning
Lamp) Check 5E1-11. . . . . . . . . . . . . . . . . . . . . . .
“ABS” Warning Lamp Check 5E1-11. . . . . . . . . . .
Diagnostic Trouble Code (DTC) Check
(Using “ABS” Warning Lamp) 5E1-11. . . . . . . . .
DTC Check (Using SUZUKI Scan
Tool) 5E1-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Trouble Code (DTC)
Clearance 5E1-13. . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 5E1
ANTILOCK BRAKE SYSTEM (ABS)
(OPTIONAL)
WARNING:
For vehicles equipped with Supplemental Restraint (Air Bag) System:
Service on and around the air bag system components or wiring must be performed only by an autho-
rized SUZUKI dealer. Refer to “Air Bag System Components and Wiring Location View” under “Gener-
al Description” in air bag system section in order to confirm whether you are performing service on
or near the air bag system components or wiring. Please observe all WARNINGS and “Service Precau-
tions” under “On-Vehicle Service” in air bag system section before performing service on or around
the air bag system components or wiring. Failure to follow WARNINGS could result in unintentional
activation of the system or could render the system inoperative. Either of these two conditions may
result in severe injury.
Technical service work must be started at least 90 seconds after the ignition switch is turned to the
“LOCK” position and the negative cable is disconnected from the battery. Otherwise, the system may
be activated by reserve energy in the Sensing and Diagnostic Module (SDM).
NOTE:
All brake fasteners are important attaching parts in that they could affect the performance of vital parts
and systems, and/or could result in major repair expense. They must be replaced with one of same part
number or with an equivalent part if replacement becomes necessary. Do not use a replacement part of
lesser quality or substitute design. Torque values must be used as specified during reassembly to assure
proper retention of all parts. There is to be no welding as it may result in extensive damage and weakening
of the metal.
CONTENTS
