YH4
GRAND
VITARA
5E1-8 ANTILOCK BRAKE SYSTEM (ABS) (OPTIONAL)
ABS DIAGNOSTIC FLOW TABLE
Refer to the following pages for the details of each step.
STEP
ACTION YES NO
1 Perform customer complaint analysis, problem
symptom confirmation and diagnostic trouble code
check record and clearance. Is there any trouble code?
Go to step 2. Go to step 5.
2 Perform driving test. Is trouble symptom identified? Go to step 3. Go to step 6.
3 Check diagnostic trouble code. Is it malfunction
code?
Go to step 4. Go to step 5.
4 Inspect and repair referring to applicable diagnostic trouble
code table in this section. Then perform final confirmation
test after clearing diagnostic trouble code. Is trouble recur?
Go to step 7. END.
5 Inspect and repair referring to DIAGNOSIS in
“BRAKES” section. Then perform final confirmation test
after clearing diagnostic trouble code. Is trouble recur?
Go to step 7. END.
6 Check for intermittent problems referring to
INTERMITTENT AND POOR CONNECTION in
“GENERAL INFORMATION” section and related circuit
of trouble code recorded in step 1. Then perform final
confirmation test after clearing diagnostic trouble code.
Is trouble recur?
Go to step 7. END.
7 Perform diagnostic trouble code check record
and clearance. Is there any trouble code?
Go to step 2. Go to step 5.
