YH4
GRAND
VITARA
ANTILOCK BRAKE SYSTEM (ABS) (OPTIONAL) 5E1-7
DIAGNOSIS
To ensure that the trouble diagnosis is done accurately and smooth-
ly, observe “Precautions in Diagnosing Troubles” and follow “ABS
Diagnostic Flow Table”.
PRECAUTION IN DIAGNOSING TROUBLES
If the vehicle was operated in any of the following ways, “ABS”
warning light may light momentarily but this does not indicate any-
thing abnormal in ABS.
– The vehicle was driven with parking brake pulled.
– The vehicle was driven with brake dragging.
– The vehicle was stuck in mud, sand, etc.
– Wheel spin occurred while driving.
– Wheel(s) was rotated while the vehicle was jacked up.
Be sure to read “Precautions for Electronic Circuit Service” in
“GENERAL INFORMATION” section before inspection and ob-
serve what is written there.
Be sure to use the trouble diagnosis procedure as described in
the flow table. Failure to follow the flow table may result in incor-
rect diagnosis. (Some other diag. trouble code may be stored by
mistake in the memory of ABS control module during inspection.)
To Next Page
