DS1067-062C 20 LBT20063
2.3 ARMING FROM 1067/026 KEYPAD
2.3.1 Total arming (system with zones only)
Proceed as follows to arm the entire alarm system if no areas are defined:
1) Enter < Master / User code > and press
.
2) The keypad will beep. Press
to exit without arming. The status LED will light up
after 5 seconds (fixed if all zones are armed, blinking if only some zones are armed).
The square will appear full indicating the zones which have been armed. The following
will appear on the display:
3) Press again if you do not want to wait for 5 seconds.
4) The display will go back to standard view automatically after one minute. Press
to go to standard view immediately.
5) If programmed or if the system is EN50131 compliant, the keypad will sound long
beeps initially followed by short beeps for the last 10 seconds.
IMPORTANT! The user will arm only the assigned zones and not necessarily all the zones even with this procedure.
2.3.2 Total arming (system with areas and zones)
Proceed as follows to arm the entire alarm system if areas are defined:
1) Enter < Master / User code / Installer / Tech. Manager > and press
.
2) Press T1 for areas or T4 for zones. Press T1 (i.e. areas) on the display. An empty
square will appear for each programmed area which is not armed assigned to the
keypad and code. Full squares indicate that the area is armed. Half-full squares indicate
that the area is only partially armed.
3) The keypad will beep. Press
to exit without arming. The status LED will light up after
5 seconds (fixed if all areas are armed, blinking if some areas are not armed). The
squares will appear full indicating the areas which are not armed. The following will
appear on the display:
4) Press
again if you do not want to wait for 5 seconds.
IMPORTANT! The user will arm only the assigned areas and not necessarily all the
areas even with this procedure.
5) If T4 (i.e. zones) was pressed instead, an empty square will appear on the display for
each programmed zone which is not armed assigned to keypad and code. Full squares
indicate that the zone is armed. Octagons (e.g.
) indicate that the zone is disarmed
and some inputs are open.
6) The keypad will beep. Press
to exit without arming. The status LED will light up after
5 seconds (fixed if all zones are armed, blinking if only some zones are armed). The
square will appear full indicating the zones which have been armed. The following will
appear on the display:
