DS1067-062C 78 LBT20063
7.3 TELEPHONE NUMBERS
The dialler of the 1067/024, 1067/032A and 1067/052A control panels may store up to 12, 12, 12 telephone numbers,
respectively. Each number may contain up to 28 digits or pauses in any combination.
Each pause lasts for 2 seconds. Simply queue pauses to obtain a longer pause. The pauses are inserted by pressing the
key and are indicated on the display by a “P”.
The stored telephone numbers may be associated to the entire system (the telephone number will be used for any event)
or to specific zones (the telephone number will be used only for the events concerning these zones).
It is possible to select which telephone network (channel) the transmitter will use to connect with the outside: the
traditional telephone landline (PSTN) or the mobile phone network (GSM). The choice will only be possible if both
networks are available (PSTN line connected to the 1067/002A module, GSM module inserted).
IMPORTANT! The GSM network cannot be used in an EN50131 compliant system.
ADVICE: By enabling the GSM answering machine: the GSM module will always be active and calls will be sent
faster.
7.3.1 How to store a telephone number
Proceed as follows to store a telephone number:
1) Enter <Master / Installer code>, press
and then .
2) Press
epeatedly until TELEPHONE DIALER appears.
3) Press
.
4) Press
.
5) Press
.
6) Press
and to select the memory position of the telephone number. Press
to confirm.
7) Enter the telephone number and press
. Press to cancel the number.
8) Press
.
9) Press
.
10) Press .
11) Press and to select the telephone number. Press to confirm.
12) Press
and to assign the telephone number to the entire system or to
specific zones. Press
to confirm.
UT01:MASTER
SYSTEM STATUS
UT01:MASTER
TELEPHONE DIALER
TELEPHONE DIALER
PHONE NUMBERS
PHONE NUMBERS
TEL. NUMBER
TEL. NUMBER
T01:...
PHONE NUMBERS
TEL. NUMBER
PHONE NUMBERS
ASSIGN TEL N.
ASSIGN TEL N.
T01:...
T01:???
SYSTEM
