5.2.2 How to navigate the menus
The menus are organised in a tree structure, i.e. with reciprocally nested submenus, each consisting of one more items.
The submenu items differ according to the access code used and the system configuration. For example, if the respective
menu items will not appear if the radio device interface is not installed. Similarly, the ENABLE menu item (users, keys etc.)
only appears in the Master menu and not in all the others.
The LCD typically shows the current menu on the first line and the submenu on the second line.
In the example shown, the EVENT LOG is the current menu and TOTAL is one of the possible submenus. The OLED
display is different but the information is displayed according to the same criteria.
The various keys used to navigate the menus are shown in the following table.
To access the menu
Confirms the entered access code, accesses the displayed submenu or confirms the selection made
Goes back to the previous page or menu level
Scrolls the menu items
Scrolls the menu items
For example, after having logged in as Installer, in the following menu item:
the following will occur when the various keys are press.
• Press
and to scroll the submenus of the ENABLE menu, i.e. INSTALLER, TECH. MANAGER, USER, KEY,
TIMED COMMANDS, ADVANCED. The submenu items appear in cycle, i.e. the first of the list appears after the last
item (in this case, INSTALLER will appear again after ADVANCED).
• Press
to access the INSTALLER submenu, which has two submenus: ENABLE AND DISABLE.
• Press
to go back to the main menu of the Master user (UT01:MASTER), in which ENABLE is one of the
submenus.
• Press
repeatedly to exit from the menu.
The system will automatically exit from the menu after a minute if no key is pressed.
A brief beep will be heard each time a key is pressed.
A beep-beep will be heard to confirm that the entered parameter is correct, i.e. when a correct access code is entered.
A long beep will be heard if an incorrect parameter is entered, i.e. if an incorrect user code is entered.
EVENT LOG
TOTAL
ENABLE
INSTALLER
To Next Page
