ABS (ANTI-LOCK BRAKE SYSTEM)
4-62
EAS30728
ABS COMPONENTS CHART
1
23
4
5
9
1
10
1112
13
8
6
7
1. Hydraulic unit assembly
2. Fuse box 3
3. Yamaha diagnostic tool coupler
4. Rear wheel sensor
5. Rear wheel sensor rotor
6. Front wheel sensor
7. Front wheel sensor rotor
8. ABS warning light
9. Fuse box 2
10.Rear brake hose (hydraulic unit to rear brake
caliper)
11.Front brake hose (front brake master cylinder
to hydraulic unit)
12.Front brake hose (hydraulic unit to front brake
caliper)
13.Rear brake hose (rear brake master cylinder
to hydraulic unit)
