LUBRICATION POINTS AND LUBRICANT TYPES
2-16
EAS30019
CHASSIS
Clutch boss conical washer
Transmission gears inner surface
Transmission collar
Transmission gears outer surface (shift fork contact parts)
Drive sprocket washer
Shift drum moving surface
Shift fork pin
Shift forks guide bar outer surface
Shift shaft washer
Shift shaft moving surface
Crankcase mating surface
Yamaha bond No. 1215
(Three bond No. 1215®)
Stator coil assembly lead grommet
Yamaha bond No. 1215
(Three bond No. 1215®)
Cylinder head cover mating surface Three Bond No. 1541C®
Lubrication point Lubricant
E
M
M
M
E
E
E
E
E
E
Lubrication point Lubricant
Steering bearings, seal lip and ball race lip
Tube guide (throttle grip) inner surface and throttle cables
Brake lever pivot bolt and metal-to-metal moving parts
Clutch lever pivot bolt, metal-to-metal moving parts and clutch cable end
Swingarm collar outer surface, oil seal lip
Pivot shaft
Swingarm pivot bush outer surface, oil seal lip
Swingarm pivot thrust cover inner surface
Relay arm collar outer surface, oil seal inner lip
Sidestand pivoting point and metal-to-metal moving parts
Sidestand switch contact point
Sidestand hook and spring contact point
Centerstand pivoting point and metal-to-metal moving parts
Centerstand hose inner surface and outer surface
Shift pedal pivoting parts
Passenger footrest ball and metal-to-metal moving parts
Shift shaft joint rod moving parts
LS
LS
S
LS
LS
LS
LS
LS
LS
LS
LS
LS
LS
LS
LS
LS
LS
