TIGHTENING TORQUES
2-13
EAS30016
ENGINE TIGHTENING TORQUES
EAS30017
CHASSIS TIGHTENING TORQUES
Item
Thread
size
Q’ty Tightening torque Remarks
Exhaust pipe nut M8 6 20 N·m (2.0 kgf·m, 14 lb·ft)
Muffler protector bolt M6 3 10 N·m (1.0 kgf·m, 7.2 lb·ft)
Spark plug M10 3 13 N·m (1.3 kgf·m, 9.4 lb·ft)
Cylinder head cover bolt M6 4 10 N·m (1.0 kgf·m, 7.2 lb·ft)
Generator rotor bolt M12 1 75 N·m (7.5 kgf·m, 54 lb·ft)
Generator cover bolt M6 2 12 N·m (1.2 kgf·m, 8.7 lb·ft)
Generator cover bolt M6 8 12 N·m (1.2 kgf·m, 8.7 lb·ft)
Clutch boss nut M20 1 125 N·m (12.5 kgf·m, 90 lb·ft)
Stake.
Clutch spring bolt M6 3 10 N·m (1.0 kgf·m, 7.2 lb·ft)
Clutch cover bolt M6 11 12 N·m (1.2 kgf·m, 8.7 lb·ft)
Oil filter cartridge M20 1 17 N·m (1.7 kgf·m, 12 lb·ft)
Oil filter cartridge union bolt M20 1 70 N·m (7.0 kgf·m, 51 lb·ft)
Water pump drain bolt M6 1 10 N·m (1.0 kgf·m, 7.2 lb·ft)
Engine oil drain bolt M14 1 43 N·m (4.3 kgf·m, 31 lb·ft)
Item
Thread
size
Q’ty Tightening torque Remarks
Front wheel axle M16 1 65 N·m (6.5 kgf·m, 47 lb·ft)
Front wheel axle pinch bolt M8 1 23 N·m (2.3 kgf·m, 17 lb·ft)
Rear wheel sprocket nut M10 6 80 N·m (8.0 kgf·m, 58 lb·ft)
Rear wheel axle nut M18 1 150 N·m (15 kgf·m, 108 lb·ft)
Rear brake caliper bolt (front) M12 1 27 N·m (2.7 kgf·m, 20 lb·ft)
Rear brake caliper bolt (rear) M8 1 22 N·m (2.2 kgf·m, 16 lb·ft) and
Brake caliper bleed screw M8 3 5 N·m (0.5 kgf·m, 3.6 lb·ft)
Front brake caliper bolt M10 4 35 N·m (3.5 kgf·m, 25 lb·ft)
Upper handlebar holder bolt M8 4 22 N·m (2.2 kgf·m, 16 lb·ft)
Lower handlebar holder nut M10 2 40 N·m (4.0 kgf·m, 29 lb·ft)
Clutch cable locknut M8 1 7 N·m (0.7 kgf·m, 5.1 lb·ft)
Lower bracket pinch bolt M8 4 23 N·m (2.3 kgf·m, 17 lb·ft)
Upper bracket pinch bolt M8 2 26 N·m (2.6 kgf·m, 19 lb·ft)
Lower ring nut M25 1 See TIP.
