SIP User's Manual 102 Document #: LTRT-65412
MP-11x & MP-124
3.3.4.3.4 Configuring the Account Table
The 'Account Table' page allows you to define accounts per Hunt Group (Served Trunk
Group) for registration and/or digest authentication (user name and password) to a
destination IP address (Serving IP Group). The Account table can be used, for example, to
register to an Internet Telephony Service Provider (ITSP) on behalf of an IP-PBX to which
the device is connected. The registrations are sent to the Proxy Set ID (refer to ''Configuring
the Proxy Sets Table'' on page 95) asso
ciated with these Serving IP Groups.
A Hunt Group can register to more than one Serving IP Group (e.g., ITSP's). This can be
achieved by configuring multiple entries in the Account table with the same Served Trunk
Group, but with different Serving IP Groups, user name/password, host name, and contact
user values.
Note: You can also configure the Account table using the ini file table parameter
Account (refer to ''SIP Configuration Parameters'' on page 252).
¾ To configure Accounts:
1. Open the 'Account Table' page (Configuration tab > Protocol Configuration menu >
Proxies/IpGroups/Registration submenu > Account Table page item).
Figure 3-62: Account Table Page
2. To add an Account, in the 'Add' field, enter the desired table row index, and then click
Add. A new row appears.
3. Configure the Account parameters according to the table below.
4. Click the Apply button to save your changes.
5. To save the changes, refer to ''Saving Configuration'' on page 167.
Note:
For a description of the Web interface's table command buttons (e.g.,
Duplicate and Delete), refer to ''Working with Tables'' on page 37.
Table 3-18: Account Table Parameters Description
Parameter Description
Served Trunk Group
[Account_ServedTrunkGroup]
The Hunt Group ID for which the device performs registration
and/or authentication to a destination IP Group (i.e., Serving IP
Group).
For Tel-to-IP calls, the Served Trunk Group is the source Hunt
Group from where the call initiated. For IP-to-Tel calls, the Served
Trunk Group is the 'Hunt Group ID' defined in the 'IP to Hunt
Group Routing' table (refer to ''Configuring the IP to Trunk Group
Routing'' on page 135). For defining Hun
t Groups, refer to
“Configuring Endpoint Phone Numbers” on page 149.
