SIP User's Manual 28 Document #: LTRT-65412
MP-11x & MP-124
3.1.2 Accessing the Web Interface
The Web interface can be opened using any standard Web browser (refer to ''Computer
Requirements'' on page 26). When initially accessing the Web in
terface, use the default
user name ('Admin') and password ('Admin'). For changing the login user name and
password, refer to ''Configuring the Web User Accounts'' on page 73).
Note:
For assigning an IP address to the device, refer to the device's Installation
Manual.
¾ To access the Web interface:
1. Open a standard Web browser application.
2. In the Web browser's Uniform Resource Locator (URL) field, specify the device's IP
address (e.g., http://10.1.10.10); the Web interface's 'Enter Network Password' dialog
box appears, as shown in the figure below:
Figure 3-2: Enter Network Password Screen
3. In the 'User Name' and 'Password' fields, enter the case-sensitive, user name and
password.
4. Click the OK button; the Web interface is accessed, displaying the 'Home' page (for a
detailed description of the 'Home' page, refer to ''Using the Home Page'' on page 54).
Note:
If access to the device's Web interface is denied ("Unauthorized") due to
Microsoft Internet Explorer security settings, perform the following
troubleshooting procedures:
1. Delete all cookies in the Temporary Internet Files folder. If this does not
resolve the problem, the security settings may need to be altered
(continue with Step 2).
2. In Internet Explorer, navigate to Tools menu > Internet Options >
Security tab > Custom Level, and then scroll down to the Logon options
and select Prompt for username and password. Select the Advanced
tab, and then scroll down until the HTTP 1.1 Settings are displayed and
verify that Use HTTP 1.1 is selected.
3. Quit and start the Web browser again.
