Version 5.8 175 September 2009
SIP User's Manual 3. Web-Based Management
10. Click End Process to close the wizard; the 'Enter Network Password' dialog box
appears.
11. Enter your login user name and password, and then click OK; a message box appears
informing you of the new cmp file.
12. Click OK; the Web interface becomes active, reflecting the upgraded device.
3.4.2.3 Backing Up and Restoring Configuration
You can save a copy/backup of the device's current configuration settings (Voice) as an ini
file to a folder on your PC, using the 'Configuration File' page. The saved ini file includes
only parameters that were modified and parameters with other than default values. The
'Configuration File' page also allows you to load an ini file to the device. If the device has
"lost" its configuration, you can restore the device's configuration by loading the previously
saved ini file or by simply loading a newly created ini file.
Note:
When loading an ini file using this Web page, parameters not included in the
ini file are reset to default settings.
¾ To save and restore the ini file:
1. Open the 'Configuration File' page (Management tab > Software Update menu >
Configuration File).
Figure 3-105: Configuration File Page
2. To save theini file to a folder on your PC, perform the following:
a. Click the Save INI File button; the 'File Download' dialog box appears.
b. Click the Save button, navigate to the folder in which you want to save the ini file
on your PC, and then click Save; the device copies the ini file to the selected
folder.
