Version 5.8 151 September 2009
SIP User's Manual 3. Web-Based Management
Note: You can also configure the Hunt Group Settings table using the ini file table
parameter TrunkGroupSettings (refer to ''Number Manipulation and Routing
Parameters'' on page 328).
¾ To configure the Hunt Group Settings table:
1. Open the 'Hunt Group Settings' page (Configuration tab > Protocol Configuration
menu > Hunt Group submenu > Hunt Group Settings page item).
Figure 3-89: Hunt Group Settings Page
2. From the 'Routing Index' drop-down list, select the range of entries that you want to
edit (up to 24 entries can be configured).
3. Configure the Hunt Group according to the table below.
4. Click the Submit button to save your changes.
5. To save the changes to flash memory, refer to ''Saving Configuration'' on page 167.
An example i
s shown below of a REGISTER message for registering endpoint "101" using registration
Per Endpoint mode. The "SipGroupName" in the request URI is taken from the IP Group table.
REGISTER sip:SipGroupName SIP/2.0
Via: SIP/2.0/UDP 10.33.37.78;branch=z9hG4bKac862428454
From: <sip:101@GatewayName>;tag=1c862422082
To: <sip:101@GatewayName>
Call-ID: 9907977062512000232825@10.33.37.78
CSeq: 3 REGISTER
Contact: <sip:101@10.33.37.78>;expires=3600
Expires: 3600
User-Agent: Audiocodes-Sip-Gateway-MP-118 FXS_FXO/v.5.40A.008.002
Content-Length: 0
Table 3-27: Trunk Group Settings Parameters
Parameter Description
Hunt Group ID
[TrunkGroupSettings_Trunk
GroupId]
The Hunt Group ID that you want to configure.
The valid range is 1 to 99.
Channel Select Mode
[TrunkGroupSettings_Chann
elSelectMode]
The method for which IP-to-Tel calls are assigned to channels
pertaining to a Hunt Group. For a detailed description of this
parameter, refer to the global parameter ChannelSelectMode.
 [0] By Dest Phone Number.
