SIP User's Manual 124 Document #: LTRT-65412
MP-11x & MP-124
Parameter Description
Destination Address
[IP2IPRouting_DestAddress]
The destination IP address (or domain name, e.g.,
domain.com) to where the call is sent.
Notes:
 This parameter is applicable only if the parameter
'Destination Type' is set to 'Dest Address' [1].
 When using domain names, enter a DNS server IP
address or alternatively, define these names in the
'Internal DNS Table' (refer to ''Configuring the Internal
SRV Table'' on page 139).
Destination Port
[IP2IPRouting_DestPort]
The destination port to where the call is sent.
Destination Transport Type
[IP2IPRouting_DestTransportType]
The transport layer type for sending the call:
 [-1] Not Configured (default)
 [0] UDP
 [1] TCP
 [2] TLS
Note: When this parameter is set to -1, the transport type is
determined by the parameter SIPTransportType.
3.3.4.7 Manipulation Tables
The Manipulation Tables submenu allows you to configure number manipulation and
mapping of NPI/TON to SIP messages. This submenu includes the following items:
îš„ Dest Number IP->Tel (refer to ''Configuring the Number Manipulation Tables'' on page
124)
îš„ Des
t Number Tel->IP (refer to ''Configuring the Number Manipulation Tables'' on page
124)
îš„ Source Number IP->T
el (refer to ''Configuring the Number Manipulation Tables'' on
page 124)
îš„ Source Number Tel->IP (refer to ''Confi
guring the Number Manipulation Tables'' on
page 124)
îš„ Phone Con
text (refer to ''Mapping NPI/TON to SIP Phone-Context'' on page 128)
3.3.4.7.1 Configuring the Number Manipulation Tables
The device provides four number manipulation tables for incoming (IP-to-Tel) and outgoing
(Tel-to-IP) calls. These tables are used to modify the destination and source telephone
numbers so that the calls can be routed correctly. For example, telephone number
manipulation can be implemented for the following:
îš„ Stripping or adding dialing plan digits from or to the number, respectively. For
example, a user may need to first dial 9 before dialing the phone number to indicate an
external line. This number 9 can then be removed by number manipulation before the
call is setup.
îš„ Allowing or blocking Caller ID information to be sent according to destination or source
prefixes. For detailed information on Caller ID, refer to Configuring Caller Display
Information on page 144.
