SIP User's Manual 42 Document #: LTRT-65412
MP-11x & MP-124
7. Click the Next button located at the bottom of the page; the Step is added to the
Scenario and appears in the Scenario Step list:
Figure 3-15: Creating a Scenario
8. Repeat steps 5 through 8 to add additional Steps (i.e., pages).
9. When you have added all the required Steps for your Scenario, click the Save &
Finish button located at the bottom of the Navigation tree; a message box appears
informing you that the Scenario has been successfully created.
10. Click OK; the Scenario mode is quit and the menu tree of the Configuration tab
appears in the Navigation tree.
Notes:
• You can add up to 20 Steps to a Scenario, where each Step can contain
up to 25 parameters.
• When in Scenario mode, the Navigation tree is in 'Full' display (i.e., all
menus are displayed in the Navigation tree) and the configuration pages
are in 'Advanced Parameter List' display (i.e., all parameters are shown in
the pages). This ensures accessibility to all parameters when creating a
Scenario. For a description on the Navigation tree views, refer to
''Navigation Tree'' on page 30.
• If you previously created a Scenario and you click the Create Scenario
button, the previously created Scenario is deleted and replaced with the
one you are creating.
• Only users with access level of 'Security Administrator' can create a
Scenario.
