SIP User's Manual 420 Document #: LTRT-65412
MP-11x & MP-124
Below is an example of RADIUS Accounting, where the non-standard parameters are
preceded with brackets.
Accounting-Request (361)
user-name = 111
acct-session-id = 1
nas-ip-address = 212.179.22.213
nas-port-type = 0
acct-status-type = 2
acct-input-octets = 4841
acct-output-octets = 8800
acct-session-time = 1
acct-input-packets = 122
acct-output-packets = 220
called-station-id = 201
calling-station-id = 202
// Accounting non-standard parameters:
(4923 33) h323-gw-id =
(4923 23) h323-remote-address = 212.179.22.214
(4923 1) h323-ivr-out = h323-incoming-conf-id:02102944 600a1899
3fd61009 0e2f3cc5
(4923 30) h323-disconnect-cause = 22 (0x16)
(4923 27) h323-call-type = VOIP
(4923 26) h323-call-origin = Originate
(4923 24) h323-conf-id = 02102944 600a1899 3fd61009 0e2f3cc5
9.13 Call Detail Record
The Call Detail Record (CDR) contains vital statistic information on calls made by the
device. CDRs are generated at the end and (optionally) at the beginning of each call
(determined by the parameter CDRReportLevel), and then sent to a Syslog server. The
destination IP address for CDR logs is determined by the parameter CDRSyslogServerIP.
For CDR in RADIUS format, refer to ''Supported RADIUS Attributes'' on page 417.
The followi
ng table lists the supported CDR fields.
Table 9-8: Supported CDR Fields
Field Name Description
ReportType
Report for either Call Started, Call Connected, or Call Released
Cid
Port Number
CallId
SIP Call Identifier
Trunk
Physical Trunk Number (always set to '-1', as not applicable)
BChan
Selected B-Channel (always set to '0', as not applicable)
ConId
SIP Conference ID
TG
Trunk Group Number
EPTyp
Endpoint Type
Orig
Call Originator (IP, Tel)
SourceIp
Source IP Address
DestIp
Destination IP Address
TON
Source Phone Number Type
NPI
Source Phone Number Plan
