Version 5.8 215 September 2009
SIP User's Manual 6. Configuration Parameters Reference
6.1.2 Multiple IP Interfaces and VLANs Parameters
The IP network interfaces and VLAN parameters are described in the table below.
Table 6-2: IP Network Interfaces and VLAN Parameters
Parameter Description
Multiple Interface Table
Multiple Interface Table
[InterfaceTable]
This ini file table parameter configures the Multiple Interface
table for configuring logical IP addresses. The format of this
parameter is as follows:
[InterfaceTable]
FORMAT InterfaceTable_Index =
InterfaceTable_ApplicationTypes,
InterfaceTable_InterfaceMode, InterfaceTable_IPAddress,
InterfaceTable_PrefixLength, InterfaceTable_Gateway,
InterfaceTable_VlanID, InterfaceTable_InterfaceName;
[\InterfaceTable]
For example:
InterfaceTable 0 = 0, 0, 192.168.85.14, 16, 0.0.0.0, 1,
Management;
InterfaceTable 1 = 2, 0, 200.200.85.14, 24, 0.0.0.0, 200,
Control;
InterfaceTable 2 = 1, 0, 211.211.85.14, 24, 211.211.85.1, 211,
Media;
The above example, configures three network interfaces
(OAMP, Control, and Media).
Notes:
Up to 16 logical IP addresses with associated VLANs can
be defined (indices 0-15). However, only up to 8 interfaces
can be used for media RTP traffic (assigned to a Media
Realm in the 'SIP Media Realm' table, which in turn is
assigned to an IP Group).
For this ini file table parameter to take effect, a device reset
is required.
Each interface index must be unique.
Each IP interface must have a unique subnet.
Subnets in different interfaces must not be overlapping in
any way (e.g., defining two interfaces with 10.0.0.1/8 and
10.50.10.1/24 is invalid). Each interface must have its own
address space.
Upon device start up, this table is parsed and passes
comprehensive validation tests. If any errors occur during
this validation phase, the device sends an error message to
the Syslog server and falls back to a “safe mode”, using a
single IPv4 interface and without VLANs. Therefore, check
the Syslog for any error messages.
When booting using BootP/DHCP protocols, an IP address
is obtained from the server. This address is used as the
OAMP address for this session, overriding the address
configured using the InterfaceTable. The address specified
for OAMP applications in this becomes available when
