SIP User's Manual 62 Document #: LTRT-65412
MP-11x & MP-124
Parameter Description
Web/EMS: Gateway
[InterfaceTable_Gateway]
Defines the IP address of the default gateway used by the
device.
Notes:
Only one default gateway can be defined .
The default gateway must be configured on an interface
that includes Media traffic.
The default gateway's IP address must be in the same
subnet as the interface address.
Apart from the interface with the defined default gateway,
for all other interfaces define this parameter to “0.0.0.0”.
For configuring additional routing rules for other interfaces,
use the Routing table (refer to Configuring the IP Routing
Table on page 65).
Web/EMS: VLAN ID
[InterfaceTable_VlanID]
Defines the VLAN ID for each interface. Incoming traffic with
this VLAN ID is routed to the corresponding interface, and
outgoing traffic from that interface is tagged with this VLAN
ID.
Notes:
The VLAN ID must be unique for each interface.
VLANs are available only when booting the device from
flash. When booting using BootP/DHCP protocols, VLANs
are disabled to allow easier maintenance access. In this
scenario, multiple network interface capabilities are not
available.
Web/EMS: Interface Name
[InterfaceTable_InterfaceName]
Defines a string (up to 16 characters) to name this interface.
This name is displayed in management interfaces (Web, CLI
and SNMP) for better readability (and has no functional use)
as well as the 'SIP Media Realm' table (refer to Configuring
Media Realms).
Note: The interface name is a mandatory parameter and must
be unique for each interface.
General Parameters
VLAN Mode
[VlANMode]
For a description of this parameter, refer to Networking
Parameters on page 213.
Native VLAN ID
[VLANNativeVlanID]
For a description of this parameter, refer to Networking
Parameters on page 213.
3.3.1.2 Configuring the Application Settings
The 'Application Settings' page is used for configuring various application parameters such
as Network Time Protocol (NTP), daylight saving time, and Telnet. For a description of
these parameters, refer to “Configuration Parameters Reference” on page 213.
