Reset palette
Resets palette pen parameters configured using Define palette.
This setting item sets the palette pen parameters back to the default.
Display this item by selecting the following.
(Setup) > Printer settings > Print settings > HP-GL/2 print settings > Line & pen manager >
Pen setup
• All palettes•
Resets all palette pen parameters.
• Palette A•
Resets Palette A pen parameters.
• Palette B•
Resets Palette B pen parameters.
PALETTE DEFAULTS
Palette defaults are the same settings as Default in the initial state.
Pen number Line Width (mm) Colors (R, G, B) Line Attributes Tip Connecting Line
0 0.13 0 (255, 255, 255) Rounds Rounds Rounds
1 0.18 1 (0, 0, 0) Rounds Rounds Rounds
2 0.25 2 (255, 0, 0) Rounds Rounds Rounds
3 0.35 3 (0, 255, 0) Rounds Rounds Rounds
4 0.50 4 (255, 255, 0) No setting No setting Miter
5 0.65 5 (0, 0, 255) No setting No setting Miter
6 0.70 6 (255, 0, 255) No setting No setting Miter
7 0.80 7 (0, 255, 255) No setting No setting Miter
8 0.90 8 (233, 233, 233) No setting No setting Miter
9 1.0 12 (127, 127, 127) No setting No setting Miter
10 1.4 19 (255, 214, 0) No setting No setting Miter
11 2.0 27 (0, 255, 214) No setting No setting Miter
12 3.0 35 (214, 0, 255) No setting No setting Miter
13 5.0 68 (205, 205, 0) No setting No setting Miter
414
