Table 24: Security Configuration Menu Options
To ChangeDescriptionOption
From Cisco Unified Communications
Manager Administration, choose Device >
Phone > Phone Configuration.
Indicates whether the access port on the
phone is enabled (Yes) or disabled
(No).
Must be set to enabled for video
support on the phone
PC Port Disabled
From Cisco Unified Communications
Manager Administration, choose Device >
Phone > Phone Configuration.
Indicates if the phone accepts MAC
addresses from Gratuitous ARP
(GARP) responses.
GARP Enabled
From Cisco Unified Communications
Manager Administration, choose Device >
Phone > Phone Configuration.
Indicates whether the phone allows a
device attached to the access port to
access the Voice VLAN. Setting this
option to No (disabled) prevents the
attached PC from sending and receiving
data on the Voice VLAN.
Setting this option also prevents the PC
from receiving data sent and received
by the phone. Set this setting to Yes
(enabled) if an application that requires
monitoring of the phone’s traffic is
running on the PC. These applications
include monitoring and recording
applications and network monitoring
software.
Voice VLAN
Enabled
For more information, see Control Web Page
Access, on page 193.
Indicates whether web access is enabled
(Yes) or disabled (No) for the phone.
Web Access
Enabled
Use Cisco Unified Communications Manager
Administration to modify.
Displays the security mode that is set
for the phone.
Security Mode
For use by the Cisco Technical Assistance Center (TAC).Logging Display
QoS Configuration Menu
The QoS Configuration menu displays information that relates to quality of service (QoS) for the phone. The
following table describes the options on this menu.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
100
Cisco Unified IP Phone Settings
QoS Configuration Menu

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
