Cisco 7941G Administration Guide

Related Topics
Softkey Templates, on page 148
Set Up Additional Buttons
To configure the 48 additional buttons, follow these steps:
Procedure
Step 1
From Cisco Unified Communications Manager Administration, choose Device > Device Settings > Phone
Button Template.
Step 2
Select the Add New button.
Step 3
From the drop-down list, choose a template and click Copy.
Step 4
Rename the new template.
Step 5
Update the table to 54 Directory Numbers for Cisco Unified IP Phone 7962G.
See Cisco Unified Communications Manager Administration Guide and Cisco Unified Communications
Manager System Guide for more information on creating and modifying templates.
You can also attach two Cisco Unified IP Phone Expansion Modules 7915s or two Cisco Unified IP
Phone Expansion Modules 7916s, to provide 48 additional lines or speed-dial and feature buttons.
Note
Footstand Adjustment
The Cisco Unified IP Phone includes an adjustable footstand. When you place the phone on a desktop surface,
you can adjust the tilt height to several different angles in 7.5 degree increments from flat to 60 degrees. You
can also mount these phones to the wall by using the footstand or by using the optional locking wall mount
kit.
To adjust the footstand, push in the footstand adjustment button and adjust the tilt.
Phone Cable Lock
You can secure the Cisco Unified IP Phone to a desktop by using a laptop cable lock. The lock connects to
the security slot on the back of the phone, and the cable can be secured to a desktop.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
53
Cisco Unified IP Phones Installation
Footstand Adjustment

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
