Cisco 7941G Administration Guide

DescriptionItem
Total number of concealment frames divided by total number of speech
frames received from start of the voice stream.
Cumulative Conceal Ratio
Ratio of concealment frames to speech frames in preceding 3-second
interval of active speech. If using voice activity detection (VAD), a
longer interval might be required to accumulate 3 seconds of active
speech.
Interval Conceal Ratio
Highest interval concealment ratio from start of the voice stream.Max Conceal Ratio
Number of seconds that have concealment events (lost frames) from
the start of the voice stream. This includes severely concealed seconds.
Conceal Secs
Number of seconds that have more than 5 percent concealment events
(lost frames) from the start of the voice stream.
Severely Conceal Secs
Estimate of the network latency, expressed in milliseconds. Represents
a running average of the round-trip delay, measured when RTCP receiver
report blocks are received.
Latency
(see note)
Identifies the current Network Protocol.Network Protocol
When the RTP Control Protocol is disabled, no data generates for this field and thus displays as 0.Note
Test Tone
The Cisco Unified IP Phone supports a test tone, which allows you to troubleshoot echo on a call as well as
to test low volume levels.
To use a test tone, you must:
•
Enable the tone generator
•
Create a test tone
Enable Tone Generator
To enable the tone generator, follow these steps:
Procedure
Step 1
Verify that the phone is unlocked.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
187
Model Information, Status, and Statistics
Test Tone

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
