Step 3
To establish the VPN connection, press Submit.
Step 4
To disable the VPN login process, press Cancel.
VPN Configuration Fields
The following table shows the VPN option on the Cisco Unified IP Phone.
Table 33: VPN Configuration Settings
To ChangeDescriptionOption
1. Choose Settings > Security
Configuration > VPN Configuration >
VPN.
2. Set the VPN option to Enabled or
Disabled.
If the feature is disabled on the Cisco
Unified Communications Manager, this
option is disabled.
Determines if the VPN Client is
enabled or disabled:
• Enable—Enables VPN feature.
When enabled, the Disable
softkey is shown.
• Disable—Disables VPN feature
When disabled, the Enable
softkey is shown.
Settings do not have to be unlocked to
set this option.
VPN
This option is inactive when the
authentication method is certificate only,
or if the feature is disabled on the Cisco
Unified Communications Manager.
Clears the current username and
password.
Clear Username and
Password
Display only—Configured on Cisco
Unified Communications Manager.
Shows if option is Enabled or Disabled.Auto Network Detection
For configured concentrators, press Select
to view concentrator details.
A new screen appears that has a title of
“Concentrator X,” where X is the
concentrator number. The URL
configured for the concentrator displays
in the window with the link to the URL
on the first line and the URL itself on the
second line.
Allows you to see if concentrator 1, 2,
or 3 is Connected or Inactive and view
the concentrator details.
In the VPN Configuration menu,
choose Concentrator 1, Concentrator
2, or Concentrator 3, as desired:
•
For a configured concentrator, a
status of Connected or Inactive
displays on the VPN
Configuration screen.
•
For an unconfigured
concentrator, no status displays,
and the Select softkey is inactive.
Concentrator 1
Concentrator 2
Concentrator 3
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
117
Cisco Unified IP Phone Settings
VPN Configuration

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
