Step 5
Scroll to the Expansion Module Information section.
Step 6
To add support for one expansion module on Cisco Unified IP Phones 7961G and 7961G-GE, in the Module
1 field, select 7914 14-Button Line Expansion Module.
Step 7
To add support for one expansion module on Cisco Unified IP Phone 7962G, in the Module 1 field, choose:
•
7914 14-Button Line Expansion Module for the Cisco Unified IP Phone Expansion Module 7914
•
7915 12-Button Line Expansion Module or 7915 24-Button Line Expansion Module for the Cisco
Unified IP Phone Expansion Module 7915
•
7916 12-Button Line Expansion Module or 7916 24-Button Line Expansion Module for the Cisco
Unified IP Phone Expansion Module 7916
Step 8
To add support for a second expansion module on Cisco Unified IP Phones 7961G and 7961G-GE, in the
Module 2 field, choose 7914 14-Button Line Expansion Module.
Step 9
To add support for a second expansion module on Cisco Unified IP Phone 7962G, in the Module 2 field,
choose:
•
7914 14-Button Line Expansion Module for the Cisco Unified IP Phone Expansion Modules 7914
•
7915 12-Button Line Expansion Module or 7915 24-Button Line Expansion Module for the Cisco
Unified IP Phone Expansion Module 7915
•
7916 12-Button Line Expansion Module or 7916 24-Button Line Expansion Module for the Cisco
Unified IP Phone Expansion Module 7916
In the Firmware Load Information section, there are two fields that specify the firmware load
for Modules 1 and 2. You can leave these fields blank to use the default firmware load.
Note
Step 10
Click the Save icon.
Step 11
Click OK.
Step 12
Click Apply Config.
Step 13
Click OK.
Feature Key Capacity Increase for Cisco Unified IP Phones
The Cisco Unified IP Phone Expansion Modules 7915 and 7916 attach to your Cisco Unified IP Phone 7962G,
adding up to 48 extra line appearances or programmable buttons to your phone. The line capability increase
includes Directory Numbers (DN), line information menu, line ring menu, and line help ID.
You can configure all 48 additional keys on the Cisco Unified IP Phone Expansion Modules 7915 and 7916.
Cisco Unified IP Phones 7961G-GE and 7941G-GE do not support Cisco Unified IP Phone Expansion
Modules 7915 and 7916.
Note
Use the Phone Button Template Configuration to configure the buttons.
Cisco Unified Communications Manager includes several default phone button templates. When adding
phones, you can assign one of these templates to the phones or create a new template.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
52
Cisco Unified IP Phones Installation
Feature Key Capacity Increase for Cisco Unified IP Phones

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
