Cisco 7941G Administration Guide

Related Topics
Display Settings Menu, on page 60
Unlock and Lock Options, on page 60
Phone Setup Options, on page 62
Network Configuration Menu, on page 64
Device Configuration Menu, on page 84
Security Configuration Menu, on page 108
Cisco Unified IP Phone Reset or Restore, on page 229
Phone Setup Options
The settings that you can change on a phone fall into several categories, as shown in the following table. For
a detailed explanation of each setting and instructions for changing them, see Network Configuration Menu,
on page 64.
There are several options on the Network Configuration menu and on the Device Configuration Menu
that are for display only or that you can configure from Cisco Unified Communications Manager. These
options are also described in this chapter.
Note
Table 8: Settings Configurable from the Phone
Network Configuration Menu OptionDescriptionCategory
General Network Settings
Admin. VLAN ID
PC VLAN
Admin. VLAN ID allows you to
change the administrative VLAN
used by the phone. PC VLAN allows
the phone to interoperate with
third-party switches that do not
support a voice VLAN.
VLAN settings
SW Port ConfigurationAllows you to set the speed and
duplex of the network and access
ports.
Port settings
PC Port Configuration
IPv4 Network Settings
DHCPDynamic Host Configuration
Protocol (DHCP) automatically
assigns IP address to devices when
you connect them to the network.
Cisco Unified IP Phones enable
DHCP by default.
DHCP settings
DHCP Address Released
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
62
Cisco Unified IP Phone Settings
Phone Setup Options

Cisco 7941G Specifications

General

Keypad number of keys	12
Touchscreen	-
Display resolution	320 x 222 pixels
Speakerphone	Yes
Voice codecs	G.729a
Bluetooth	No
Supported network protocols	DHCP, TFTP, SCCP, DSCP
Ethernet LAN (RJ-45) ports	2
Input voltage	48 V
Dimensions (WxDxH)	266.7 x 152.4 x 203.2 mm
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Safety	(UL) 60950, (CSA) C22.2 No. 60950, IEC 60950, EN 60950, AS/NZS 60950
Certification	CE (FCC) 15 (CFR 47) B ICES-003 B EN55022 B CISPR22 B AS/NZ 3548 B VCCI B EN55024 EN 50082-1 EN 61000-3-2 EN 61000-3-3
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3af
Lines quantity	- lines
Phonebook capacity	- entries
Number of handles included	1 pc(s)

Weight and Dimensions

Weight	1600 g
